SKU: CW-12KV3BLK

Carbon 12K - 12000lb Winch V3 with MegaPro Hook

$899.00 $977.00 -8% OFF

Carbon Offroad Mega Pro Winch Hook (Choose Your Colour)

BLACK BLUE GREEN ORANGE RED YELLOW PINK SANDY TAUPE PURPLE SILVER

The Carbon 12K is a lightweight, high-performance 12000lb winch designed to handle tough off-road conditions.

Engineered in Australia and refined through real-world use.

With a powerful 6.2HP motor, IP68 waterproof rating, and a durable triple planetary gearbox, it’s built for consistent pulling power through mud, sand, and steep terrain.

Supplied as a complete kit with everything you need - wired and wireless remotes (both included), synthetic rope, CNC alloy fairlead, isolator switch, and all mounting hardware - it’s ready for installation straight out of the box.

The control box offers flexible mounting options, and the multi-fit fairlead ensures compatibility with most bars. Backed by a lifetime mechanical warranty and 5-year electrical and water ingress cover, the Carbon 12K Winch delivers long-term value with no compromises.

River crossings and mud runs are stress-free. This winch features a breathable membrane-style motor breather for heat expansion and contraction. The Carbon Winch gets your recovery done with ease by using the wireless or wired remote (both included) from the safety and convenience of your driver's seat.

IP68 meaning - Ingress Protection
6 - Can withstand dust and dirt
8 - Can be submerged under freshwater for 30 minutes up to 5' depth, but not during operation.

The Carbon Winch is a proven performer with year on year sales growth and countless recoveries from the mud bogs of Tassie to the river crossings of the Cape. For peace of mind it's backed here in Australia by a class leading 5 year water ingress & electrical warranty and a lifetime geartrain warranty. We also stock a warehouse of replacement parts here in Australia to get you back winching if the need arises.

If you're capable with a few basic tools, installing a Carbon Winch is easy, with step by step instructions and many extras included to get the job done. We also thought of your safety by including an isolator switch with extra cabling, so when you're not using your winch it's safely turned off and no live power wires are at the front of your vehicle.

Mounting the control box is easy with a multi fit system that can either be mounted on the winch, above the winch drum or motor. Or with the bracket can be mounted to the vehicle or on top of your bullbar. As you know, "looks" are a big part of any 4x4 build, so we have included in your winch kit an ultra sexy CNC'd anodised alloy signature Carbon fairlead paired with our own robust designed hook that makes you stand out from the crowd. Weight is a serious consideration with all 4wd accessories, the Carbon Winch is super lightweight at only 55lb

Carbon Winches 12K Winch is a 12000lb line pull winch and can meet the rugged demands of off-road and utility use in Australian conditions. It is designed to deliver the best value, reliability and service life for a winch user.

Get a winch you can trust.

Technical Features Performance Specs Dimensions Installation & User Guide Warranty Videos
  • Part number: CW-12k
  • Rated line pull: 12000lb, (5450 kg) single-line
  • Motor: 12V DC 6.2HP series wound motor (24V option available)
  • Remote Control: Remote Switch, 12ft (3.7m) lead.
  • Wireless Remote Control: Included
  • Geartrain: 3-Stage Planetary.
  • Gear Ratio: 216:1
  • Clutch (free spooling): Rotating Ring Gear clutch with manual pull and twist clutch handle
  • Brake: Full load automatic brake installed in the motor housing end plate.
  • Fairlead: Multi-fit CNC billet alloy black anodised with laser etched logo
  • Lifetime Mechanical Warranty
  • 5 Year Electrical Warranty
  • 5 Year Water Ingress Protection Warranty
  • Synthetic Rope: 24m x 10mm diameter
  • Drum Diameter/Length: 64mm x 224mm
  • Mounting Bolt Pattern: 254mm x 114.3mm
  • Recommended Battery: 650 CCA minimum for winching
  • Winch Dimensions (L x W x H): 21.7'' x 6.3'' x 6.8'' (552 x 160 x 172mm)
  • Packing Dimensions (L x W x H): 24.2" x 14.5" x 9.8" (615 x 370 x 250mm)
  • Winch weight with synthetic rope attached: 42lb
  • Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 57.2lb
12V DC Performance Specs
Line Pull Line Speed Motor Current Pull By Layer
0 lbs (0 kg) 43.3 ft/min (13.2 m/min) 70 amps 1/12000 (5450)
2000 lbs (910 kg) 11.5 ft/min (3.5 m/min) 130 amps 2/9800 (4450)
4000 lbs (1810 kg) 9.2 ft/min (2.8 m/min) 170 amps 3/8300 (3770)
6000 lbs (2720 kg) 7.9 ft/min (2.4 m/min) 220 amps 4/7200 (3270)
8000 lbs (3630 kg) 6.9 ft/min (2.1 m/min) 265 amps 5/6400 (2900)
10000 lbs (4540 kg) 5.6 ft/min (1.7 m/min) 320 amps 6/5800 (2650)
12000 lbs (5450 kg) 4.6 ft/min (1.4 m/min) 390 amps 7/5300 (2420)

The Carbon Story

Carbon Winches are designed, engineered and tested by Australian Offroad Business - KPD Industries. A 4 year project began in 2012 to build a winch that would surpass all market options that were available at the time. After that, the Carbon Winch brand was launched in June 2016 and since then has developed a solid reputation for reliability, toughness and has been tested in some of the harshest environments in Australia and overseas including the USA, Iceland and the Middle East.

But in addition, we didn't stop there - We made the winch even better.
Many other products on the market simply didn't prove worthy in the Australian Outback including some very popular world renowned brands, so we built our own. A strong following in the Australian market developed with proven results across thousands of customers and 5 years on the market. A full redesign of the winch over a 6 month period between January and June 2021, results in the V2 CW-12K, a culmination of 5 years of using, supplying and receiving feedback from our customers and dealer network as we improved on many aspects of the original market proven winch design.
